VW 2.0 16V ABF Wiseco pistons CR 8.5 83mm KE188M83

Part number KE188M83
Wiseco forged piston kit (4 pcs.) 83.00mm CR 8.5:1
VW / Seat - 2.0 16V (ABF)
699,00 €
Доступность:0 шт.
Информация

Product detailed specification

Bore size

83.00mm

Stroke

92.80mm

Wiseco compression ratio (CR)

8.5:1

OEM compression ratio (CR)

10.5:1

Dome volume (CC)

-11cm3

Compression height (CH)

30.60mm

Pin diameter

21mm

Features

FSR series skirt

Fits for

VW / Seat - 2.0 16V ABF

Wiseco ArmorGlide skirt coating is a dry film lubricant applied to the piston skirt. This coating helps reduce friction, improving performance, and will also help quiet the piston in the cylinder bore. This coating is permanently applied, and is not a break in coating, it is on the piston for the life of the part.

Вам также может понравиться

Audi/VW 1.8 2.0 8V, 2.0 16V ABF 2E FCP X-beam steel connecting rods 159mm
Product detailed specification

Manufacturer: FCP Engineering
Model: FCPRXVW15950621-4
Profile: X-beam (Oiling channel from big end to piston pin)
C to C: 159mm
Big end diameter: 50.6mm
Pin diameter: 21mm
Quantity: 4 pcs., 8 pcs. ARP2000 3/8" bolts
Made of: forged steel 4340 EN24er
Advertised horsepower rating: 1000HP (4 cylinder)
Advertised RPM rating: 9000RPM
Audi / VW 1.8 8V, 2.0 8V, 2.0 16V engines with 236mm block (ABF, ABA, AAD, 2E)
499,00 €
VW / Seat 2.0 16V ABF Turbo FCP forged pistons kit 83mm CR 8.8

Part number: FCPPVW83T
Manufacturer: FCP Engineering
Forged high performance pistons for various applications in nearly all engine types for racing and street use.
Made of 4032-T6, piston skirt is molibden coated.
Bore size: 83.00mm
Stroke: 92.80mm
Dome dish: -11cc

Compression ratio (CR): 8.8:1
Compression height (CH): 31.60mm
Connecting rod length must be: 159mm
Piston pin: 21mm HD tool steel pin designed for high boost application
VW Golf III, Passat / Seat Cordoba, Ibiza, Toledo - 2.0 16V (ABF) Turbo

649,00 €
VW / Seat 2.0 16V ABF JE Pistons kit CR 8.5 83mm 325749C

Product detailed specification

Bore size

83.00mm

Stroke

92.80mm

JE Pistons compression ratio (CR)

8.5:1

OEM compression ratio (CR)

10.5:1

Dome volume (CC)

-9.4cm3

Compression height (CH)

30.60mm

Pin diameter

21mm

Features

Accepts Turbo and Nitrous; FSR series skirt

Fits for

VW / Seat - 2.0 16V ABF

849,00 €
Audi / VW 2.0 8V-16V AAD ABF 2E FCP H-beam steel connecting rods 159mm

Product detailed specification

Manufacturer: FCP Engineering
Model: FCPRHVW15950621-4
Profile: H-beam
C to C: 159mm
Big end diameter: 50.6mm
Pin diameter: 20/21mm (optional)
Quantity: 4 pcs., 8 pcs. ARP2000 3/8" bolts
Made of: forged steel 4340 EN24er
Advertised horsepower rating: 600HP (4 cylinder)
Advertised RPM rating: 9000RPM

Audi / VW 2.0 8V, 2.0 16V engines with 236mm block (ABF, ABA, AAD, 2E)
399,00 €
Audi / VW 1.6 1.8 2.0 ACL Race connecting rod bearings 4B1606H-STD
ENGINE BEARINGS

CON ROD BEARING SET

Part#
4B1606H

4B1606HX


Sizes STD, .025, .25, .50 STD
Oil Clearance Standard + 0.001" Extra
Half Type Identical Halves
Material

Tri-metal Hardened steel backs

Min Std Shaft Size

1.8802" /47.758mm

Max Std Shaft Size

1.8810" /47.778mm

Min Std Tunnel Size

1.9921" /50.600mm

Max Std Tunnel Size

1.9929" /50.619mm

Max Wall at Crown

0.0553" / 1.405mm

0.0548" /1.392mm

Max Overall Length

0.748" / 19.00mm

Notes Bearing has 1.65mm oil hole at crown

Diagram
(Top View)


Engines Audi / VW - 1.6 1.8 2.0 (2V, 4V, 5V, Turbo applications, 1983-2003)

70,00 €
VW 2.0 16V ABF Wiseco pistons CR 8.5 82.5mm KE188M825

Product detailed specification

Bore size

82.50mm

Stroke

92.80mm

Wiseco compression ratio (CR)

8.5:1

OEM compression ratio (CR)

10.5:1

Dome volume (CC)

-11cm3

Compression height (CH)

30.60mm

Pin diameter

21mm

Features

FSR series skirt

Fits for

VW / Seat - 2.0 16V ABF

Wiseco ArmorGlide skirt coating is a dry film lubricant applied to the piston skirt. This coating helps reduce friction, improving performance, and will also help quiet the piston in the cylinder bore. This coating is permanently applied, and is not a break in coating, it is on the piston for the life of the part.
729,00 €
