BMW M3 E46 3.2 S54B32 King Racing connecting rod bearings CR6877XP-STDX

BMW M3 E46 3.2 S54B32 JE Pistons kit CR 12.5 87.5mm 297120

Product detailed specification
Bore size	87.50mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	12.5:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-9.20cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; FSR skirt
Fits for	BMW M3 E46 3.2 S54B32

1 059,00 €

BMW M3 E46 3.2 S54B32 forged JE Pistons kit 87mm CR 9.0 297115

Product detailed specification
Bore size	87.00mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	9.0:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-29.30cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; assymetrical FSR series
Fits for	BMW M3 E46 - 3.2 S54B32

1 059,00 €

BMW M3 E46 S54B32 ACL Race connecting rod bearings 6B1569H-0.25

Part number 6B1569H-0.25
ACL Race Series connecting rod bearings
BMW M3 E46 - 3.2 (S54B32)

	CON ROD BEARING SET
	Part#
	6B1569H	6B1569HX
Sizes	STD, .025, .25	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Identical Halves
Material	Tri-metal Hardened steel backs
Min Std Shaft Size	1.9281in / 48.975mm
Max Std Shaft Size	1.9288in / 48.991mm
Min Std Tunnel Size	2.0866in / 53.000mm
Max Std Tunnel Size	2.0872in / 53.015mm
Max Wall at Crown	0.0785in / 1.993mm
Max Overall Length	0.630in / 16.00mm
Notes

199,00 €

BMW M3 E46 S54B32 ACL Race connecting rod bearings 6B1569HX-STD

Manufacturer: ACL Bearing company
Part number: 6B1569HX-STD
BMW M3 E46 - 3.2 (S54B32)

	CON ROD BEARING SET
	Part#
	6B1569H	6B1569HX
Sizes	STD, .025, .25	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Identical Halves
Material	Tri-metal Hardened steel backs
Min Std Shaft Size	1.9281in / 48.975mm
Max Std Shaft Size	1.9288in / 48.991mm
Min Std Tunnel Size	2.0866in / 53.000mm
Max Std Tunnel Size	2.0872in / 53.015mm
Max Wall at Crown	0.0785in / 1.993mm
Max Overall Length	0.630in / 16.00mm
Notes

199,00 €

BMW M20 M50 M52 M54 S50 S54 King Racing main bearings MB7039XP-0.25

XP	XP

F7016U-PR	F7039L-PR

XP	XP

M7016U-PR	M5578L-PR

Quantity

1

6

Crankshaft

59.990 / 59.972

Housing

65.001 / 65.019

Max Wall

2.494

Max Length

24.940

19.901

Engines: BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

199,00 €

BMW M20 M50 M52 M54 S50 S54 King Racing main bearings MB7039XP-STDX

XP	XP

F7016U-PR	F7039L-PR

XP	XP

M7016U-PR	M5578L-PR

Quantity

1

6

Crankshaft

59.990 / 59.972

Housing

65.001 / 65.019

Max Wall

2.494

Max Length

24.940

19.901

Engines: BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

199,00 €

BMW M20 M50 M52 M54 S50 S54 King Racing main bearings MB7039XPC-STD Coated

XP	XP

F7016U-PR	F7039L-PR

XP	XP

M7016U-PR	M5578L-PR

Quantity

1

6

Crankshaft

59.990 / 59.972

Housing

65.001 / 65.019

Max Wall

2.494

Max Length

24.940

19.901

Engines: BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

235,00 €

BMW M3 E46 3.2 S54B32 King Racing connecting rod bearings CR6877XP-STD

Position

Connecting rod:
1, 2, 3, 4, 5, 6

Pairs
&
Part Numbers

XP	XP

C6877-PR	C6877-PR

Quantity

6

Crankshaft Diameter

48.992 / 48.974mm

Housing Diameter

53.000 / 53.015mm

Max Wall Thickness

1.994mm

Max Length

16.002mm

Engines BMW 3.2 (S54B32)

190,00 €

BMW M3 E46 3.2 S54B32 King Racing connecting rod bearings CR6877XP-0.25

Position

Connecting rod:
1, 2, 3, 4, 5, 6

Pairs
&
Part Numbers

XP	XP

C6877-PR	C6877-PR

Quantity

6

Crankshaft Diameter

48.992 / 48.974mm

Housing Diameter

53.000 / 53.015mm

Max Wall Thickness

1.994mm

Max Length

16.002mm

Engines BMW 3.2 (S54B32)

190,00 €

BMW M3 E46 3.2 S54B32 Wiseco forged pistons 87.25mm CR 11.1:1 KE126M8725

Product detailed specification
Bore size	87.25mm
Stroke	91.00mm
Wiseco pistons compression ratio (CR)	11.1:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-14.00cm³
Compression height (CH)	32.00mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; Full round piston skirt
Fits for	BMW M3 E46 - 3.2 S54B32

1 099,00 €

BMW M3 E46 3.2 S54B32 ARP main stud kit 201-5002

ARP is a manufacturer of fasteners/bolts found in engines and drivelines, ranging from OEM replacement parts to specialty hardware for racing applications. ARP is the world leader in fastener technology.

209,00 €

BMW M3 E46 3.2 S54B32 forged JE Pistons 87.5mm CR 9.0 297116

Product detailed specification
Bore size	87.50mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	9.0:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-30.00cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; assymetrical FSR series
Fits for	BMW M3 E46 - 3.2 S54B32

1 059,00 €

BMW M3 E46 3.2 S54B32 JE Pistons kit CR 11.5 87.5mm 297118

Product detailed specification
Bore size	87.50mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	11.5:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-13.80cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; FSR skirt
Fits for	BMW M3 E46 - 3.2 S54B32

1 059,00 €

BMW M3 E46 3.2 S54B32 FCP H-beam steel connecting rods 139mm

Product detailed specification

Manufacturer: FCP Engineering
Model: FCPRH1395321/S54
Profile: H-beam
C to C: 139mm
Big end diameter: 53mm
Pin diameter: 21mm
Quantity: 6 pcs., 12 pcs. ARP2000 bolts
Made of: forged steel 4340 EN24er
Advertised horsepower rating: 1000HP (6 cylinder)
Advertised RPM rating: 9000RPM
BMW M3 E46 - 3.2 (S54B32)

579,00 €

BMW M20 M50 M52 M54 S54 ACL Race main bearings 7M1532H-STD

ENGINE BEARINGS
	MAIN BEARING SET
	Part#
	7M1532H	7M1532HX
Sizes	STD, .025, .25, .50	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Upper & Lower
Material	Tri-metal
Min Std Shaft Size	2.3611in / 59.971mm
Max Std Shaft Size	2.3618in / 59.990mm
Min Std Tunnel Size	2.5591in / 65.000mm
Max Std Tunnel Size	2.5598in / 65.019mm
Max Wall at Crown	0.0980in / 2.490mm	0.0930in / 2.478mm
Max Overall Length	0.787in / 20.00mm #1,2,3,4,5,7 0.982in / 24.94mm #6 thrust
Notes
Diagram (Top View)

Engines BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

209,00 €

BMW M20 M50 M52 M54 S54 ACL Race main bearings 7M1532H-0.25

ENGINE BEARINGS
	MAIN BEARING SET
	Part#
	7M1532H	7M1532HX
Sizes	STD, .025, .25, .50	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Upper & Lower
Material	Tri-metal
Min Std Shaft Size	2.3611in / 59.971mm
Max Std Shaft Size	2.3618in / 59.990mm
Min Std Tunnel Size	2.5591in / 65.000mm
Max Std Tunnel Size	2.5598in / 65.019mm
Max Wall at Crown	0.0980in / 2.490mm	0.0930in / 2.478mm
Max Overall Length	0.787in / 20.00mm #1,2,3,4,5,7 0.982in / 24.94mm #6 thrust
Notes
Diagram (Top View)

Engines BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

209,00 €

BMW M20 M50 M52 M54 S54 ACL Race main bearings 7M1532HX-STD

ENGINE BEARINGS
	MAIN BEARING SET
	Part#
	7M1532H	7M1532HX
Sizes	STD, .025, .25, .50	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Upper & Lower
Material	Tri-metal
Min Std Shaft Size	2.3611in / 59.971mm
Max Std Shaft Size	2.3618in / 59.990mm
Min Std Tunnel Size	2.5591in / 65.000mm
Max Std Tunnel Size	2.5598in / 65.019mm
Max Wall at Crown	0.0980in / 2.490mm	0.0930in / 2.478mm
Max Overall Length	0.787in / 20.00mm #1,2,3,4,5,7 0.982in / 24.94mm #6 thrust
Notes
Diagram (Top View)

Engines BMW - 2.0 2.2 2.3 2.5 2.7 2.8 3.0 3.2 (M20 (just for variant with two bearing locks), M50B20, M52B20, M50B25, M52B25, M54B25, M54B30, M50B27, S50B30, S50B32, S52B32, S54B32)

209,00 €

BMW M3 E46 3.2 S54B32 JE Pistons CR 11.5 87mm 297117

Product detailed specification
Bore size	87.00mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	11.5:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-13.20cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; FSR skirt
Fits for	BMW M3 E46 - 3.2 S54B32

1 059,00 €

BMW M3 E46 3.2 S54B32 JE Pistons kit CR 12.5 87mm 297119

Product detailed specification
Bore size	87.00mm
Stroke	91.00mm
JE Pistons compression ratio (CR)	12.5:1
OEM compression ratio (CR)	11.3:1
Dome volume (CC)	-8.70cm³
Compression height (CH)	32.30mm
Pin diameter	21mm
Features	Accepts Turbo and Nitrous; FSR skirt
Fits for	BMW M3 E46 3.2 S54B32

1 059,00 €

BMW M3 E46 S54B32 ACL Race connecting rod bearings 6B1569H-STD

Manufacturer: ACL Bearing company
Part number: 6B1569H-STD
BMW M3 E46 - 3.2 (S54B32)

	CON ROD BEARING SET
	Part#
	6B1569H	6B1569HX
Sizes	STD, .025, .25	STD
Oil Clearance	Standard	+ 0.001" Extra
Half Type	Identical Halves
Material	Tri-metal Hardened steel backs
Min Std Shaft Size	1.9281in / 48.975mm
Max Std Shaft Size	1.9288in / 48.991mm
Min Std Tunnel Size	2.0866in / 53.000mm
Max Std Tunnel Size	2.0872in / 53.015mm
Max Wall at Crown	0.0785in / 1.993mm
Max Overall Length	0.630in / 16.00mm
Notes

199,00 €

BMW M3 S54B32 Xtreme Performance 230mm Ceramic Twin Plate Clutch KBM23550-2E

Product Details

Torque (Nm): 1800
Clamp Load: 1350Kg
Flywheel Step: +3.8mm
Clutch Disc Diameter (mm): 230
Clutch Disc Spline Count: 10
Clutch Disc Spline Diameter (mm): 35
Recommended for: Motorsport
Design: Twin Plate
Stage: Track Use Only
Weight (kg): 14.75

1 799,00 €

BMW M3 E46 3.2 S54B32 King Racing connecting rod bearings CR6877XP-0.5

Position

Connecting rod:
1, 2, 3, 4, 5, 6

Pairs
&
Part Numbers

XP	XP

C6877-PR	C6877-PR

Quantity

6

Crankshaft Diameter

48.992 / 48.974mm

Housing Diameter

53.000 / 53.015mm

Max Wall Thickness

1.994mm

Max Length

16.002mm

Engines BMW 3.2 (S54B32)

190,00 €

BMW M3 E46 3.2 S54B32 King Racing connecting rod bearings CR6877XP-STDX
